Mitochondrial Staining and Immunofluorescence Using MitoTracker Deep Red

LMU Munich
Anaesthesiology
Researcher

Overall

Quality of Results

Ease-of-Optimization

What do these ratings mean?
Write a Review

Company:

Cell Signaling Technology

Product Name:

MitoTracker® Deep Red

Catalog Number:

8779

Here, we used the MitroTracker Red to stain mitochondria in Human Umbilical Vein Endothelial Cells (HUVEC) to asses mitochondrial dynamics and integrity under flow conditions.

Experimental Design and Results Summary

Application

Immunofluorescence

Starting Material

HUVEC, cultured under flow

Tips

Be aware of photobleaching.

Results Summary

We used mitotracker red to visualize mitochondrial networks and dynamics in Human Umbilical Vein Endothelial Cells (HUVEC) under flow.

DOI or PMID #

N/A

Image Gallery

Summary

The Good

Strong fluorescence, easy to use, cells are fixable, easily combinable with green dyes.

The Bad

Rather fast photobleaching, resolution lower in the far red spectra.

The Bottom Line

Very easy to use reagent. Specific, strong fluorescence. Fixable with methanol, enabling costaining of extra and even intracellular targets. Even the architecture and mitochondrial networsk were detectable at a 63x magnification. It is also possible to combine Deep Red with another staining using green fluorescence (such as Alexa 488) and simultaneously record the fluorescence sinde we observed no "bleeding through" in the other channel when not using DAPI. You need very low laser power, however, be aware of faster photobleaching when using this dye in comparison to organic dyes.
