Fig 2: Hepatic gck:GFP in diabetic pdx1-/- larvae is unaffected by nutrients.a Experimental setup and timeline created in https://BioRender.com. Hepatic GFP expression at 6 dpf control and pdx1-/- larvae (b, c), and at 10 dpf following 5 days of minimal diet (b’, c’) or HFD (b”, c”). Signal in the gut is caused by autofluorescence of ingested food. Scale bar 200 µm. d Quantification of GFP signal in the liver of 6 dpf MIN and HFD fed control and pdx1-/- larvae. Dot plots with indicated mean. Statistical significance assessed by t-test. e Quantification of GFP signal in the liver of 10 dpf MIN and HFD fed control and pdx1-/- larvae. Dot plots with indicated mean. Statistical significance assessed by Two-way ANOVA, P-values of multiple comparisons are indicated. f Quantification of GFP signal in the liver of 6 and 10 dpf MIN and HFD fed control and pdx1−/− larvae. Dot plot with indicated mean, SD and lines connecting related groups. g Gck gene expression levels analyzed via RT-qPCR in MIN and HFD fed control and pdx1-/- larvae (N > 3). Dot and bar plot shows mean with SD. Statistical significance assessed by Two-way ANOVA. P-values of multiple comparisons are indicated. h Measurement of Gck activity in MIN and HFD fed control and pdx1-/- larvae (N > 3) shown in a dot plot with indicated mean. Two-way ANOVA indicated a significant effect of the genotype (P = 0.0147), but no significant differences in the multiple comparison. Indicated P-values are from t-tests.

Fig 3: Gck:GFP indicates gck expression in islet cells.a Most β-cells express gck:GFP (solid arrows) as observed in 5 dpf double transgenic gck:GFP;ins:dsRed larvae. b Immunohistochemistry reveals gck:GFP expression in all Somatostatin labeled islet cells (solid arrows) at 5 dpf. c At 5 dpf, gck:GFP expression is rarely observed in Glucagon expressing α-cells (as labeled by anti-gcg antibody, solid arrows). Open arrows highlight hormone producing cells lacking gck:GFP staining. Scale bar: 50 µm.

Fig 4: Gck isoforms and their expression in the zebrafish.a Genomic structure of the zebrafish gck gene and the three transcript isoforms. Exons are indicated by black rectangles and introns by lines, curved arrows represent the sites of transcription initiation. b Quantification of overall gck RNA counts from sorted adult zebrafish pancreatic cells (N = 3 biological replicates)28 and embryonic hepatocytes (N = 2 biological replicates for each time point)29. Plot shows Min to Max. c Heat map showing gck isoform expression in sorted zebrafish pancreatic α-, β- and δ-cells and embryonic hepatocytes at 4–6 dpf using the same published datasets28,29 and the improved zebrafish transcriptome annotation of Lawson et al.26.

Fig 5: Gck shows nutrient dependent expression in the liver and constitutive expression in the endocrine islet at different developmental stages.Whole mount in situ hybridization at 4 dpf shows gck expression in the developing liver as shown in lateral and ventral view (a and a’) and in the endocrine islet (a”). Expression at 5 dpf expands with the development of the liver (b and b’) and is constitutive in the islet (b”). At 6 dpf expression in the liver is almost undetectable (c and c’), while expression in the islet is visible (c”). Expression is prominent in fed 10 dpf larvae in the liver (d and d’). Expression in the islet in fed 10 dpf larvae is not detectable (d”), which is likely due to limited penetration of the RNA-probe. Scale bar: 100 µm and 20 µm.
